SMC 1000 ST
Three-Line Solar Message Center
Manufactured to the same quality standards Work Area Protection is recognized for, the SMC 1000 ST meets all the requirements of the MUTCD, while offering unparalleled ease of maintenance and programming.
Features
- On-board dedicated NTCIP-compliant controller
- 5 LEDs per pixel provide uniform light output
- Energy-efficient LED display provides minimal battery maintenance and long operational life
- Automatic intensity control provides optimum LED intensity
- Industrial-grade trailer provides stable platform
- Powder-coat finish for improved fade and scratch resistance
- Simplistic programming
- Durable in-frame LED tail lights
- On-board charger provides option of solar or AC charging
- Quick-clip access for ease of display maintenance
- State-of-the-art charge technology reduces battery overcharge incidents
- Remote programming option available
- 5-year standard warranty
On-board dedicated NTCIP controller provides easy programming with secure password protection
SMC 1000 ST Unit Specifications
- Raised Height – 158″ (4.01 m)
- Travel Height – 103″ (2.61 m)
- Width – 96″ (2.43 m)
- Length with tongue – 168″ (4.26 m)
- Length w/o tongue – 130″ (3.3 m)
- Weight – 1920 lbs (870.89 Kg)
- Energy Source – (6) 6-volt Deep Cycle batteries
- Generator – solar panel array 140 Watts
- Operating Temperature Range – -20 to +120 degrees F (-29 to +49 degrees C)
- Lift Mechanism – Leak-resistant electro-hydraulic
- Main Frame – 2″ x 4″ x .120″ high-grade steel
Sign Case Specifications
- Height – 70″ (1.76 m)
- Width – 127″ (3.22 m)
- Character Height – 18″ (46 cm)
- Lamp – LED (5 per pixel)
- Legibility – 1000 ft (304 m)
- Characters – 3 rows, 8 characters per row
Computer Specifications
- Control Console Display: LCD
- Pre-programmed Messages: 250
- User-programmed Messages: 100
- NTCIP-compliant software
- Update Speed: 100 Milliseconds
- Removable Solid State Design
- Off-the-shelf QWERTY keyboard
Six 6-Volt Deep Cycle Batteries and hydraulic pump are standard
One piece polycarbonate display window
LED trailer lights standard and inset into trailer frame
5 LEDs per pixel enhance light output and provide a more uniform pixel definition
What you get with the SMC 1000 ST
Ease of Computer Programming
A user-friendly dedicated computer designed by Work Area Protection reduces the number of keys required to program the Message Center. The unit provides NTCIP compliant functionality.
LED Lamp Pixel Design
The SMC 1000 ST uses 5 high-intensity, solid-state LEDs per 2-inch pixel. This creates a more uniform light output in each pixel, resulting in increased message definition and distance legibility.
Industrial-Grade Structural Steel Trailer
The SMC 1000 ST uses a durable trailer system designed to provide years of dependable service. The trailer’s high-quality powder-coat finish, 2″x 4″ 11-gauge steel frame and a 3,500-pound suspension system enhance the overall quality of the unit.
Modular Electronic Componentry
The entire system was developed with the operator/end user in mind. Electronic components are easily replaced, reducing downtime and maintenance costs. This modularity also improves system diagnostics.
